Building an Automatic Speech Recognition (ASR) System with PyTorch & Hugging Face

Automatic speech recognition (ASR) is a crucial technology in many applications, from voice assistants to transcription services. In this tutorial, we aim to build an ASR pipeline capable of transcribing speech into text using pre-trained models from Hugging Face. We will use a lightweight dataset for efficiency and employ Wav2Vec2, a powerful self-supervised model for speech recognition.

Our system will:

Load and preprocess a speech dataset
Fine-tune a pre-trained Wav2Vec2 model

Evaluate the model's performance using word error rate (WER)
Deploy the model for real-time speech-to-text inference

To keep our model lightweight and efficient, we will use a small speech dataset rather than large datasets like Common Voice.

Step 1: Installing Dependencies

Before we start, we need to install the necessary libraries. These libraries will allow us to load datasets, process audio files, and fine-tune our model.

pip install torch torchaudio transformers datasets soundfile jiwer

The main purpose for the following libraries:

transformers: Provides pre-trained Wav2Vec2 models for speech recognition
datasets: Loads and processes speech datasets

torchaudio: Handles audio processing and manipulation
soundfile: Reads and writes .wav files

jiwer: Computes the WER for evaluating ASR performance

Step 2: Loading a Lightweight Speech Dataset

Instead of using large datasets like Common Voice, we use SUPERB KS, a small dataset ideal for quick experimentation. This dataset consists of short spoken commands like "yes," "no," and "stop."


from datasets import load_dataset

dataset = load_dataset("superb", "ks", split="train[:1%]")  # Load only 1% of the data for quick testing
print(dataset)

This loads a tiny subset of the dataset to reduce computational cost while still allowing us to fine-tune the model. Warning: the dataset still requires storage space, so be mindful of disk usage when working with larger splits.

Step 3: Preprocessing the Audio Data

To train our ASR model, we need to ensure that the audio data is in the correct format. The Wav2Vec2 model requires:

16 kHz sample rate
No padding or truncation (handled dynamically)

We define a function to process the audio and extract relevant features.


import torchaudio

def preprocess_audio(batch):
    speecharray, samplingrate = torchaudio.load(batch["audio"]["path"])
    batch["speech"] = speech_array.squeeze().numpy()
    batch["samplingrate"] = samplingrate
    batch["target_text"] = batch["label"]  # Use labels as text output
    return batch

dataset = dataset.map(preprocess_audio)

This ensures all audio files are loaded correctly and formatted properly for further processing.

Step 4: Loading a Pre-trained Wav2Vec2 Model

We use a pre-trained Wav2Vec2 model from Hugging Face's model hub. This model has already been trained on a large dataset and can be fine-tuned for our specific task.


from transformers import Wav2Vec2Processor, Wav2Vec2ForCTC

processor = Wav2Vec2Processor.from_pretrained("facebook/wav2vec2-base-960h")
model = Wav2Vec2ForCTC.from_pretrained("facebook/wav2vec2-base-960h")

Here we define both the processor that converts raw audio into model-friendly features and the model, consisting of a Wav2Vec2 pre-trained on 960 hours of speech.

Step 5: Preparing Data for the Model

We must tokenize and encode the audio so that the model can understand it.


def preprocessformodel(batch):
    inputs = processor(batch["speech"], samplingrate=16000, returntensors="pt", padding=True)
    batch["inputvalues"] = inputs.inputvalues[0]
    return batch

dataset = dataset.map(preprocessformodel, removecolumns=["speech", "samplingrate", "audio"])

This step ensures that our dataset is compatible with the Wav2Vec2 model.

Step 6: Defining Training Arguments

Before training, we need to set up our training configuration. This includes batch size, learning rate, and optimization steps.


from transformers import TrainingArguments

training_args = TrainingArguments(
    output_dir="./wav2vec2",
    perdevicetrainbatchsize=4,
    evaluation_strategy="epoch",
    save_strategy="epoch",
    logging_dir="./logs",
    learning_rate=1e-4,
    warmup_steps=500,
    max_steps=4000,
    savetotallimit=2,
    gradientaccumulationsteps=2,
    fp16=True,
    pushtohub=False,
)

Step 7: Training the Model

Using Hugging Face's Trainer, we fine-tune our Wav2Vec2 model.


from transformers import Trainer

trainer = Trainer(
    model=model,
    args=training_args,
    train_dataset=dataset,
    tokenizer=processor,
)

trainer.train()

Step 8: Evaluating the Model

To measure how well our model transcribes speech, we compute the WER.


import torch
from jiwer import wer

def transcribe(batch):
    inputs = processor(batch["inputvalues"], returntensors="pt", padding=True)
    with torch.no_grad():
        logits = model(inputs.input_values).logits
    predicted_ids = torch.argmax(logits, dim=-1)
    batch["predictedtext"] = processor.batchdecode(predicted_ids)[0]
    return batch

results = dataset.map(transcribe)
werscore = wer(results["targettext"], results["predicted_text"])
print(f"Word Error Rate: {wer_score:.2f}")

A lower WER score indicates better performance.

Step 9: Running Inference on New Audio

Finally, we can use our trained model to transcribe real-world speech.


import torchaudio
import soundfile as sf

speecharray, samplingrate = torchaudio.load("example.wav")
inputs = processor(speecharray.squeeze().numpy(), samplingrate=16000, return_tensors="pt", padding=True)

with torch.no_grad():
    logits = model(inputs.input_values).logits

predicted_ids = torch.argmax(logits, dim=-1)
transcription = processor.batchdecode(predictedids)

Conclusion

And that's it. You've successfully built an ASR system using PyTorch & Hugging Face with a lightweight dataset.
